Belt line features

1, belt conveyor structure is simple, convenient maintenance, energy consumption is lower than other types of conveyor.

2, belt conveyor can transport a wide variety of materials, can transport a variety of scattered materials, transport a variety of cartons, bags and other light weight products, can also be used in large supermarkets at the checkout goods transport, a wide range of uses.

3, belt conveyor structure in various forms, horizontal belt machine, turning belt machine form, conveyor belt can also add baffle, side baffle, skirt and other accessories, can meet the transport route, product quality, safety needs.

4, the belt conveyor adopts special food grade PU\PE conveyor belt, which can meet the requirements of food, pharmaceutical, daily chemical and other industries.

5, the conveying process runs smoothly, there is no relative movement between the material and the conveyor belt, effectively avoid the damage to the conveying material.

6, compared with other types of conveyor, the noise is smaller, to meet the noise requirements of the working environment quiet occasions.

Belt line scope of application

It is widely used in electronics, household appliances, food, automobile, motorcycle and other industries of zero-part transportation, assembly, packaging and other fields.

Belt type pipeline technical parameters

1, pipeline conveying form: strip workbench, independent workbench, unilateral workbench, bilateral workbench and no workbench conveying form, also according to customer needs.

2, the form of drive is: motor drive delivery form.

3, the belt commonly used width: 20 ~ 2000mm, can also be customized according to customer requirements.

4, conveyor belt material: rubber belt, PVC belt, canvas belt, food belt and so on.

5, conveyor belt in the form of: conveyor belt with baffle, belt, flat belt and anti-skid belt, etc..

6, working table size according to the user.

7, work table: stick fire board, ordinary rubber, anti-static rubber lamp, oil rubber, high temperature rubber.

8, line support: stainless steel, aluminum, carbon steel spray, square tube, etc.

9, conveying speed is generally 0.1 ~ 10M/min; Can also be used according to user needs speed control or fixed speed.

10, speed regulation: frequency conversion speed regulation, electromagnetic speed regulation, electronic speed regulation, mechanical speed regulation, etc.
